Promise Technology Pegasus R4i
Choosing Advanced Conguration
This option enables you to directly specify all parameters for a new disk array, logical drives, and spare
drives.
TousetheAdvancedCongurationWizard:
1. From the Storage menu choose Wizard.
2. Click the Advanced button.
The Create Disk Array screen displays.
Task 1 – Disk Array Creation
To create your disk array:
1. Accept the defaults or make changes:
• Enter an alias in the Alias eld.
Maximum of 32 characters; letters, numbers, space between characters, and underscore.
• Media Patrol – Uncheck to disable on this array.
For more information, see “Media Patrol” on page 51.
• PDM – Uncheck to disable on this array.
For more information, see “PDM” on page 57.
2. In the Select Physical Drives diagram, click the drives to add them to your array.
The drive modules turn blue when you click them. The physical drives’ ID numbers appear in the
eldbelowthediagram.
3. Click the Next button to continue.
The Create Logical Drive screen displays.
Advanced Conguraon - Create Disk Array
