Promise Technology Pegasus R4i
Toolbar Icons
The default toolbar icons are listed here:
• Dashboard icon – Displays the Dashboard and overview
• Wizard icon - Displays the Wizard options for quickly setting up RAID arrays
• Physical Drive icon – Displays the physical drive list, settings and functions
• Disk Array icon - Display menu for monitoring, managing and creating disk arrays
• Logical Drive icon – Displays the logical drive list, settings and functions
• Subsystem Information icon – Displays Pegasus unit information and settings
• Events icon – Displays the event logs
Customizing the Toolbar
You can customize the toolbar by adding or removing icons. To add and remove toolbar icons:
1. From the Promise Utility window, click the View menu and choose Customize Toolbar...
The toolbar options dialog box appears.
2. Do one or both actions are needed:
• Click and drag an icon from the dialog box to the toolbar to add the icon.
• Click and drag an icon from the toolbar to delete the icon.
3. Whenyouarenished,clicktheDone button.
Customize toolbar
