Promise Technology Pegasus R4i
Locating a Disk Array
ThisfeaturecausesthedrivemoduleLEDstoashforoneminutetoassistyouinlocatingthephysical
drives that make up this disk array.
To locate a disk array:
1. Do one of the following actions:
• From the Dashboard window, click the Disk Array link.
• From the Storage menu, choose Disk Array.
2. Mouse-over the disk array you want then click the Locate button.
The Drive Power / Status LED for the physical drives that make up the disk array blink blue and
orange for one minute.
Running the Locate funcon to idenfy a disk array
Drive Status LEDs
Activity LEDs
