Managing the Pegasus R4iPegasus R4i Product Manual
Locating a Physical Drive
This feature causes the drive module LEDs to blink for one minute to assist you in locating the physical
drive, and is supported by RAID enclosures and JBOD expansion units.
To locate a physical drive:
1. Click the Physical Drive icon.
2. Mouse-over the physical drive you want then click the Locate button.
The Drive Status LED for the drive module holding that drive blinks blue and orange for one
minute.
Running the Locate funcon to idenfy a physical drive
Drive Status LEDs
Activity LEDs
