Promise Technology Pegasus32 R6 User Manual

2
Promise Technology Pegasus32 R4/R6/R8
Architecture
ThePegasus32architectureisbasedonastate-of-the-artPMCSierra8067I/Oprocessorcoupledwith
1G of DDR3-1866 SDRAM memory and a world class enterprise-proven RAID engine.
Protocol SuPPort
Pegasus32 supports Thunderbolt™ 3 and USB 3.2 Gen 2 technology, providing two channels
withamaximum40Gb/softhroughputinbothdirectionssimultaneously.Thunderbolt™3isNOT
COMPATIBLE with the previous versions of Thunderbolt™ (i.e. Thunderbolt™ and Thunderbolt™ 2).
Pegasus32 features one DP 1.4 port capable of driving an 8K monitor. DisplayPort standard DP 1.4
supports content via both Thunderbolt™ or USB Type-C.
Thunderbolt™ 3 supports daisy-chaining up to six (6) high-speed peripheral devices, including external
disks, and video capture devices.
Pegasus32 has two Type-C ports, that work on either Thunderbolt™ mode or USB mode. Daisy-
chaining is supported on Thunderbolt™ mode as required.
Key BenefitS
• Use Thunderbolt™ 3 or USB 3.2 Gen 2
(viatwoThunderbolt™3/USB3.2Gen2Type-Cportsandcabling)
• Thunderbolt™340Gb/sdataconnection
• USB3.2Gen210Gb/sdataconnection
• DP 1.4 port supports 8K monitor
• Mac/WindowsOSin-box(ornative)drivers
• Powerchargingsupportedupto85W
• PMCSierra8067I/Oprocessor
• 1G of DDR3-1866 SDRAM memory
• Pegasus Utility management tool
• Compatible with Apple Time Machhine
• R6, six SATA 3.5-inch hard disk drives
• R4, four SATA 3.5-inch hard disk drives
• R8, eight SATA 3.5-inch hard disk drives
• Additional storage using multiple daisy-chained Pegasus32 enclosures
• 250WFlex-ATAPowerwith80PlusBronze.

Promise Technology Pegasus32 R6 Specifications

General

Brand	Promise Technology
Model	Pegasus32 R6
Category	Storage
Language	English
