IntroductionPegasus32 Product Manual
Storage Disks
The Pegasus32 is shipped with 3.5 inch SATA Hard Disk Drives (HDD) installed in the
drive carriers and placed in the drive bays.
Capacity
The Pegasus32 is available in three form factors that differ in the number of drives that
canbeinstalled.TotalcapacitydependsonthesizeoftheHDDshippedwiththeunit.
The Pegasus32 R4 is shipped with four HDD
The Pegasus32 R6 is shipped with six HDD
The Pegasus32 R8 is shipped with eight HDD
In addition, Pegasus32 enclosures can be connected or “daisy-chained” to other
Pegasus32 units to scale up the available storage capacity.
Power supply
250WFlex-ATAPowerwith80PlusBronzewithPFC,100-230Vauto-ranging,
50-60HzAC
System Fan
Pegasus32R4/R6:Dimension:92(W)x92(H)x25(D)mm/Airow:70CFM
Pegasus32R8:Dimension:120(W)x120(H)x25.8(D)mm/Airow:97CFM
RAID function
RAID level support: RAID 0, 1, 1E, 5, 6, 10, and
RAID50(Pegasus32R6/R8only)
RAID 60 (Pegasus32 R8 only)
OS Support
Windows10x64
macOS 10.14 and above
Hardware
monitoring
Fan,Temperature,Power,Enclosure,Physicaldrives,Logicaldrives,RAIDcontroller
Temperature
Operating: 5° ~ 35° C
Non-operating:-40°~70°C
Humidity
Operating:10%~95%non-condensing
Storage:5%-95%non-condensing
Dimensions
R8:248x188x314mm(9.8x7.4x12.4in)
R6:248x188x235mm(9.8x7.4x9.3in)
R4:248x188x195mm(9.8x7.4x7.7in)
Weight
As shipped with all 3.5” HDD installed:
R8:11kg/24.2lb
R6:9.1kg/20.1lb
R4:6.8kg/15lb
Certication
CE,FCC,VCCI,RCM,BSMI,MSIP,SPRING,BIS,TUV,cTUVus
