Promise Technology Pegasus32 R4/R6/R8
Hardware
This section provides a brief introduction to the external hardware of the Pegasus32 R4, R6 and R8.
TheR4isshorterandhasfourdrivecarriers,theR8istallerwitheightdrivecarriers.Forthepurposeof
installation they are nearly identical.
Link LED
Powerbutton/
Status LED
DrivePower/
Status LED
Drive Carrier
Drive Activity LED
Pegasus32 R6 front view
