Push here when returning
or replacing the carrier
into an empty drive bay.
Pull here to release the carrier handle latch.
Then pull the carrier straight out by the han-
dle. Place your free hand under the carrier.
Do not drop the disk carrier, even if it is empty.
Tabs for locking mechanism insert. This piece must be removed
to unlatch the carrier. To remove, squeeze the tabs together and
pull out. To reinsert, squeeze the tabs together and replace in
position. Do not discard the locking mechanisms.
Vess A3340 Disk carrier with HDD installed - front view
Caution
The Vess A-Series supports disk drive hot-swapping. To avoid hand contact
with an electrical hazard, do not remove more than one drive carrier a time.
20
Vess A Class NVR Storage Appliance Promise Technology
