Block Response from Module to Processor
Word Offset
Description
Length
0
0
1
1
Write Block ID
1
2
First digit of dotted IP address
1
3
Second digit of dotted IP address
1
4
Third digit of dotted IP address
1
5
Last digit of dotted IP address
1
6 to 248
Spare data area
243
249
9990
1
Get Module IP Address Block (9991)
Block Request from Processor to Module
Word Offset
Description
Length
0
9991
1
1 to 247
Spare data area
247
Block Response from Module to Processor
Word Offset
Description
Length
0
0
1
1
Write Block ID
1
2
First digit of dotted IP address
1
3
Second digit of dotted IP address
1
4
Third digit of dotted IP address
1
5
Last digit of dotted IP address
1
6 to 248
Spare data area
243
249
9991
1
