3.0 Access Levels
There are three access levels to allow users of different authorisation levels access to various parts of
the system. The access levels and a description of functions available are given in the next sections.
3.1 Access Level 1 (General User)
Access level 1 allows the general user to view the status of the panel at any time. Zone fire,
fault, disablement and test states are clearly displayed as are any current system faults and
disablements.
Full detail of the front panel display is given in the next section.
The following functions may be performed at access level 1.
• Entering code for access level 2 or 3a
• Viewing current fires
• Viewing current faults
• Viewing current disablements
• Viewing current tests
• Accepting current faults or alarms ( Mute Buzzer )
Accepting at access level 1 is only available if the button has been made available
during the commissioning stage
3.2 Access Level 2 (Authorised / Trained User)
Access level 2 allows the authorised user access to various critical system functions.
To enter access level 2 enter the user code using the touchscreen LCD (section 12.8).
Refer to section 13 for the features accessible at access level 2.
3.3 Access Level 3a (Exchange Loop Devices)
Access level 3a allows the maintenance staff access to the loop device exchange function.
To enter access level 3a enter the level 3a code using the touchscreen LCD (section 12.8).
Refer to sections 13 & 14 for the features accessible at access level 3a.
