RDM0001/3_2 Page 25 of 70 © 2015 - 2017 Protec Fire Detection plc
12.7 Loop Selection
Each loop card has two loops. Touch to select the correct loop. During commissioning of the system,
the loops can be assigned text relevant to their location to assist in finding the appropriate one.
Note :- A loop with 000 devices may not be selected
12.8 Device Selection
Each loop comprises up to 200 devices. Search the list for the correct device then touch to select it.
Note :- Only addresses with a device assigned will be displayed.
