5.0 Fire Indications
The panel displays fire information on the LCD along with the General Fire indicator and the relevant
zone indicators. The following sections detail the meaning of each indicator.
5.1 General Fire Indicator Illuminated
The panel has detected a fire on one of its zones, or has been activated from another panel
via the network.
The building fire plan should be executed immediately
5.2 Zone Indicator Flashing Red
The panel has detected a fire in the zone shown. The General Fire indicator will always
accompany this and the internal buzzer will be fast pulsing.
