RDM0001/3_2 Page 22 of 70 © 2015 - 2017 Protec Fire Detection plc
12.2 Navigating the menus
Touching the up arrow scrolls up a menu list. If already at the top of the list then a
touch of this button wraps round to the bottom of the menu list.
Touching the down arrow button scrolls down a menu list. If already at the bottom
of the list then a touch of this button wraps round to the top of the menu list.
Some menu options require a number of steps to select from a menu list. To avoid
having to exit then go through the whole process again, touching this arrow selects the
previous item in the menu list. This button will eventually wrap round from the top of the
list to the bottom.
Some menu options require a number of steps to select from a menu list. To avoid
having to exit then go through the whole process again, touching this arrow selects the
next item in the menu list. This button will eventually wrap round from the bottom of the
list to the top.
To leave any menu, touch the EXIT button. As a security measure the panel will exit
the menus automatically if no key activity has been detected for 30 minutes.
