Psion Teklogix 7530 - Assigning an IP Address

Chapter 2: Basic Checkout
Assigning An IP Address
24
Psion Teklogix 7530 Hand-Held Computer User Manual
2.2.3 Assigning An IP Address
If your network is not using a DHCP server, you will need to assign an IP address.
• In the
$NETWLAN1 Settings window, press the <TAB> key followed by the
<LEFT> arrow key to display the IP Information tab.
Figure 2.11 IP Information
Note: Choosing the Renew button forces the 7530 to renew or find a new IP
address. This is useful if, for example, you are out of communication
range for a longer period of time and your 7530 is dropped from the net-
work.
To define a static IP address:
• Highlight the
Configure... button, and press <ENTER>.
Figure 2.12 Defining An IP Address
