2.3.3.4 Alarm Mode
The type of audible alarm can be set to PULSE or CONTINUOUS during judgment in the
measure display. The instrument default setting is PULSE. To change the alarm mode press
[SYSTEM SETUP], [SYSTEM CONFIG] and the down arrow [⇓] until the box next to ALARM
MODE is highlighted, then press [F1] = PULSE for the alarm to sound in a pulse tone or [F2] =
CONTINUOUS for the alarm to sound continuously.
Alarm will Pulse*
Alarm will Continuously sound*
F1
F2
< SYSTEM CONFIG >
PULSE
CONTINUOUS
TRIG DELAY
ALARM MODE
TEST PARAMETER :
BEEPER
SOUND MODE
TRIG EDGE
HANDLER MODE :
:
:
:
:
:
L.C.
LOW
FAIL
PULSE
0000 mS
FALLING
CLEAR
*(Until Discharge is pressed)
2.3.3.5 Trigger Delay
The trigger delay is the amount of time between the activation of a trigger (via IEEE, Handler or
front panel) and the 1855 making the measurement. The delay time can be programmed from
0000 to 9995 seconds. The instrument default value is 0000 seconds. To change the TRIGGER
DELAY press [SYSTEM SETUP], [SYSTEM CONFIG] and the down arrow [⇓] until the box
next to TRIGGER DELAY is highlighted, then press [F1] = DIGIT UP to increase the delay
time, [F2] = DIGIT DOWN to decrease the delay time or [F3] = DIGIT to move over a decimal
place.
0 - 9995 mS
9995 - 0 mS
F3
F1
F2
F4
< SYSTEM CONFIG >
DIGIT UP
DIGIT DOWN
TRIG DELAY
ALARM MODE
TEST PARAMETER :
BEEPER
SOUND MODE
TRIG EDGE
HANDLER MODE :
:
:
:
:
:
L.C.
LOW
FAIL
PULSE
0000 mS
FALLING
CLEAR
DIGIT
Move cursor to next digit
2.3.3.6 Trigger Edge
Select on which edge the measurement is triggered: FALLING or RISING. The instrument
default setting is FALLING. To change the TRIGGER EDGE press [SYSTEM SETUP],
[SYSTEM CONFIG] and the down arrow [⇓] until the box next to TRIGGER EDGE is
highlighted, then press [F1] = FALLING or [F2] = RISING.
Initiate Trigger on Falling Edge
Initiate Trigger on Rising Edge
F3
F1
F2
F4
< SYSTEM CONFIG >
FALLING
RISING
TRIG DELAY
ALARM MODE
TEST PARAMETER :
BEEPER
SOUND MODE
TRIG EDGE
HANDLER MODE :
:
:
:
:
:
L.C.
LOW
FAIL
PULSE
0000 mS
FALLING
CLEAR
