2.5 MEAS DISPLAY
The 1855 instrument’s stand-by display is the MEAS DISPLAY. After power has been applied
to the instrument and it cycles quickly through the information screen, the instrument reverts to
the MAIN INDEX. Once [SEQ. TEST] or [STEP TEST] is selected the instrument enters the
MEAS DISPLAY. To view the instrument information screen as illustrated in Figure 2.10,
press [SYSTEM SETUP] then [⇐].
QUADTECH 1855
LEAKAGE CURRENT/IR METER
Copyright (c) AUGUST 2003
VERSION 1.02 BETA .09.02 CPLD:1855
TEL 1-800-253-1230 FAX 1-978-461-4295
Figure 2.10: Instrument Information Screen
1.0V
0.5mA
NEXT PAGE 1/2
2uA
Lc :
< MEAS DISPLAY: SEQ. TEST >
A
TEST V.
C.C.
RANGE
:
:
:
DISCHARGECHARGE TEST
Vm = 0.0V
0 S
0.2 S
NEXT PAGE 2/2
MEDIUM
Lc :
< MEAS DISPLAY: SEQ. TEST >
A
CHG T.
DWELL T
SPEED
:
:
:
DISCHARGECHARGE TEST
Vm = 0.0V
A
Figure 2.11: MEAS DISPLAY- SEQUENCE TEST
1.0V
0.5mA
NEXT PAGE 1/2
2uA
Lc :
< MEAS DISPLAY: STEP TEST >
A
TEST V.
C.C.
RANGE
:
:
:
DISCHARGECHARGE TEST
Vm = 0.0V
INT
MEDIUM
NEXT PAGE 2/2
Lc :
< MEAS DISPLAY: STEP TEST >
A
TRIGGER
SPEED
:
:
DISCHARGECHARGE TEST
Vm = 0.0V
A
Figure 2-12: MEAS DISPLAY – STEP TEST
