2.5.10 Maximum Charge Time (CHG Tend)
In the W.V. Test only, the charge time can be programmed from 5 to 600seconds. In MEAS
DISPLAY press [F4] = CHG Tend so that the 5 s box is highlighted. Use the up or down arrow
keys to in/decrease the charge time by 10 second increments. The left and right arrows will
increase/decrease the time in 5 second increments. The instrument default setting is 5s.
F4
505 - 600s
by base-1
5 - 505s
by base-10
Select CHG Tend
50.0 V
CHG Tend
Tr :
< MEAS DISPLAY: W.V. TEST >
S
Vf
C.C
:
:
DISCHARGECHARGE TEST
Vm = 0.0V
Tend :
:
Vt : V
0.15
58.00
58.0V / 30.15S
2.0 mA
Tr+ 30 s
5s
UP arrow [⇑] key: 5 → 15 → 25 → 35 → 45 → 55 → 65 → 75 → 85 → 95 → 105 → 205 →
305 → 405 → 505.
RIGHT arrow [⇒] key: increase charge time in 1 second increments. (example: 505 to 600)
DOWN arrow [⇓] key: 600 → 500 → 400 → 300 → 200 → 100 → 90 → 80 → 70 → 60 → 50
→ 40 → 30 → 20 → 10.
LEFT arrow [⇐] key: decrease charge time in 1 second increments. (example: 10 to 5)
