Quantum QXS 12G Series User Manual

40 QXS 12G Site Planning Guide
Figure 37 5U84 Expansion Chassis Rear View (SAS)
Expansion Chassis IOM
Figure 38 provides a rear view of the expansion chassis IOM used in the 5U84-drive systems. Ports
A/B/C ship configured with 12Gb/s HD mini-SAS (SFF-8644) external connectors.
Figure 38 Expansion Chassis IOM
1
5
2
3
4
7
6
9
8
1
IOM A
2
IOM B
3
Fan 0
4
Fan 1
5
Fan 2
6
Fan 3
7
Fan 4
8
PSU 0
9
PSU 1
2 3
4
1
5
6
1
SAS Port
2
SAS Port A
3
SAS Port B
4
SAS Port C
5
Ethernet Port
6
Lock/Release Handle
