Troubleshooting
QL-800 User Guide 87
3 Open the main side door.
4 Lift the roller handle [2] to open the input pinch rollers. There are two rollers on the
top and one roller on the bottom of the media entry slot. The rollers must be open
to allow removal of the transport unit and remaining media in the next step.
[2]
