Getting Started
QL-800 User Guide 21
13 Close the top cover. The printer will feed media as needed and the media loading
process will be complete.
Note: If the manual media feeding process fails, the media will be ejected back out
of the printer.
Unloading Media
1 Press and hold the back-feed key. The printer will back-feed media.
When the media has almost exited the back of the printer, back-feeding will stop
and the printer will beep once. This confirmation tone alerts you that media is about
to be unloaded.
2 To continue and unload media, press and hold the back-feed key again. Media will
back-feed fully out of the printer.
3 Loosen the captive fastener on the outer flange [1]. Then remove the flange from
the mandrel.
4 Turn the wing nut [2] on the end of the mandrel counterclockwise to loosen the
mandrel. Loosen the wing nut until the media roll moves freely.
5 Remove the media roll from the mandrel.
