Quick Start
14 Kiaro! 50 User Guide
10 While pressing on the top of the media guide (A), move it to the media width
measurement (B) corresponding to the total width of the media.
For example, in the illustration the guide has been moved to the guide position “54
mm.”
11 Pass the media leading edge under the sensor (D), and align it with the media
alignment line (B).
Check that media does not float above the media guides (A and C). If it is hard to
feed media in, check whether the media guide is positioned properly.
If media has a large slack, take it up onto the media roll to remove the slack
appropriately. Media having a large slack may touch the media set lever, causing
the printer to malfunction.
Note: Ensure that the media guide (A) does not press the media and prevent
media movement.
A
B
A
B
C
D
To Next Page
