SFC6400A/SFC1450A Synthesized Frequency Upconverter User Interfaces
TM106 – Rev. 1.1 4-15
Decimal ID Converter Function System Type
0 Not Used Not Used
1 Primary 1 1F8
2 Primary 2 1F8
3 Primary 3 1F8
4 Primary 4 1F8
5 Primary 5 1F8
6 Primary 6 1F8
7 Primary 7 1F8
8 Primary 8 1F8
9 Backup 1F8
10 Backup 1F1
11 Primary 1F1
12 – 14 Not Used Not Used
15 Stand Alone (ID Bits
pulled up on Controller
Card)
Stand Alone
CONVERTER TYPE: {DN CONVERTER, UPCONVERTER}
Indicates whether the unit is an Upconverter or a
Upconverter. This display will match the text on the Front
Panel Overlay.
CONVERTER BAND: {C-BAND, KU-BAND}
Indicates whether the unit is a C-Band or Ku-Band
Converter. This display will match the text on the Front
Panel Overlay.
FREQUENCY TYPE: {70 MHz, 140 MHz}
Indicates the IF type of the Converter.
SYNTHESIZER: {MFS-1191, MFS-448, MFS-459, MFS-544, MFS-881,
MFS-474, MFS-4.47, MFS-4.59}
Displays the model number of the unit's installed
synthesizer. The frequency range of each model is given
below:
