10
PD 1309.6269.62-02
Unless expressly permitted, never remove 15.
the cover or any part of the housing while the
product is in operation. Doing so will expose
circuits and components and can lead to
injuries, re or damage to the product.
For permanently installed equipment without 16.
built-in fuses, circuit breakers or similar
protective devices, the supply circuit must be
fused in such a way that suitable protection is
provided for users and products.
Do not insert any objects into the openings 17.
in the housing that are not designed for this
purpose. Never pour any liquids onto or into the
housing. This can cause short circuits inside the
product and/or electric shocks, re or injuries.
Use suitable overvoltage protection to ensure 18.
that no overvoltage (such as that caused
by a thunderstorm) can reach the product.
Otherwise the operating personnel will be
endangered by electric shocks.
Do not place the product on heat-generating 19.
devices such as radiators or fan heaters. The
temperature of the environment must not
exceed the maximum temperature specifi ed in
the data sheet.
Batteries and storage batteries must not be 20.
exposed to high temperatures or fi re. Keep
batteries and storage batteries away from
children. Do not short-circuit batteries and
storage batteries. If batteries or storage
GalaxyE_v1-10_3.indd 10GalaxyE_v1-10_3.indd 10 08.04.2009 15:21:3708.04.2009 15:21:37
