WARNING: This manual DOES NOT replace an adequate diving training !
Computer’s technical characteristics
Hardware
The computer is made in composite material - stainless steel and mineral glass (Easy and Deep version) or Sapphire glass
(Tech+ version).
The screen is provided with a TFT, IPS, 1.3-Inch, 240x240 pixel, 261 ppi, 100% matrix Color display .
Particular dedication has been put in developing a navigation system allowing the diver to have access to the different
settings in an easy and intuitive way.
- Sensor’s guaranteed precision: 130 mt.
- Maximum depth: 150mt / 500ft (Easy and Deep version) - 220mt / 721 ft (Tech+ version)
- Absolute Pressure Measurement precision
min max
p = 0 .. 5bar -20 mbar +20 mbar
p = 0 .. 10bar -40 mbar +20 mbar
p = 0 .. 14bar -100 mbar +20 mbar
- Sensor’s maximum error margin in measuring Temperature: -2 / +6°C
If worn at wrist the temperature measurement in air is conditioned by body’s heat. For an accurate temperature measurement, put the device in water or leave it far
from heat sources for some minutes.
- Recharge the iDive using a PS1 category (EN 62368) (not included)
- Supply voltage: 5V c.c. +/-0.2V 500mAh
Certication
The computer’s hardware comply with CE EN13319, ETSI EN 301 489-3, EN 61000-6-1, EN 61000-6-3 requirements.
