2.8 Code designations on the connection ports of the MPR2
Ext. connection port for device extension (RS232)
Out-1 connection port for analogue output 1
Out-2 connection port for analogue output 2
PC connection port for USB cable
Power connection port for mains adapter
P1 connection port for pressure sensor P1
P2/T2 multi-purpose port for pressure sensor P2 / temperature sensor T2
pO2 connection port for fibre-optical partial oxygen pressure sensor
T1 connection port for temperature sensor T1
2.9 Catheter location and signal designations
ART Arterial pressure
CPP Cerebral Perfusion Pressure
DIA Diastolic pressure
GP1, GP2, GP3 general pressure parameters (without specific catheter location)
IBP Invasive Blood Pressure
ICP Intra-Cranial Pressure
ICPA Intra-Cranial Pressure Pulse Amplitude
MAP Median Arterial Pressure
MD1 Median pressure D1
MD2 Median pressure D2
MD3 Median pressure D3
UL Upper limiting value
pO2, ptiO2 Partial oxygen pressure
SYS Systolic pressure
T1 Temperature T1
T2 Temperature T2
LL Lower limiting value
CVP Central venal pressure
