4.4.4.1 Changing the temperature settings
The right-hand column of the display holds the navigation field, in which you can use the soft keys to carry
out further adjustments or to call off information or help.
Additional settings of the temperature channels are accessed by pressing the keys T1 or T2. If you have
connected additional sensors, other soft key designations will be displayed with the defined measuring
locations.
Temperature T1
Range with alarm limits
Alarm activation
Press the Menu key, if you
want to modify the
highlighted field
In this window you can use the arrow keys to select whether you want to set alarm limits and whether the
limiting value monitor of the selected measuring value is to be active or not.
Proceed correspondingly, if you want to change the settings for temperature T2.
Do not set the limiting values to extreme figures which could render the alarm system useless.
4.4.4.1.1 Setting the limiting temperature values
Increasing the lower limiting value:
Keep the LL+ key pressed until the
requested value is reached.
Lowering the upper limiting value:
Keep the UL- key pressed until the
requested value is reached.
Acknowledge the settings by
pressing OK. Leave the window by
pressing OK, if no other changes
are required.
You will
now access the overview
of the measured values. The new
limiting values will be displayed,
provided Yes has been activated
for the parameter Active.
If you want to change other settings or repeat a setting, press the key T1 or T2, if another temperature
sensor has been connected.
