Instructions for Use RAUMEDIC
MPR2 logO
Manufacturer: zwo-400EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9 2020-09-22
Page 51 of 99
4.4.3.6 pO2 graphics
In order to skip to the graphics screen, press the key . Screen will be accessed.
Freeze curve
Increase recording speed
Four recording speeds are available:
1, 5, 10 und 30 mm/s
Reduce recording speed
Numeric display
measured value pO2
Recording speed
Set marker
Use the key or to switch over the plotting speed. 30 mm/s correspond to approx. 3 s per display
width. Use the key to reduce the plotting speed, increasing the time basis of the curve.
Press Start to continue
recording process
Use the key to freeze the current curve, which is released by pressing the key .
This document is for information only
