Instructions for Use RAUMEDIC
MPR2 logO
Manufacturer: zwo-400EN
RAUMEDIC AG, Hermann-Staudinger-Strasse 2, 95233 Helmbrechts, Germany Rev. 9 2020-09-22
Page 21 of 99
Designation Definition
pO2
ST connector for partial oxygen
pressure
P2/T2
Multi-purpose connector for digital
memory, invasive pressure P2 and
temperature T2
Table 4: Connections for the partial oxygen pressure probe
The allocation of the measuring location of the channel sets its scale, alarm source and alarm limits.
As the partial oxygen pressure probes are multi-purpose probes as a rule, which combine partial oxygen
pressure measurement, invasive pressure measurement and temperature measurement in one catheter,
the notes rendered hereto shall have to be observed as well.
Specification of the pressure channels: cf. chapter 11 Technical parameters (Specification)
Recommended accessories: cf. chapter 9 Accessories
