CHAPTER 2
10 Viper Pro Installation & Operation Manual
Nut - 3/8” - 16 Zinc Flanged
Lock
312-1001-164 34 14 34 14
Nut - 5/16” - 18 Nylon Insert
Lock
312-4000-059 3 3 3 3
Nut - 3/8” - 16 Nylon Insert
Lock
312-4000-061 3 N/A 3 N/A
Nut - 1/2” - 13 Nylon Insert
Lock
312-4000-065 1 1 1 1
Nut - 3/4” - 10 Nylon Insert
Lock
312-4000-071 4 4 4 4
O-Ring - 9/16” ID Buna-N 219-0001-015 4 N/A 4 N/A
Washer - 5/16” Flat 313-2300-011 8 8 8 8
Washer - 1/2” Flat 313-2300-017 2 2 2 2
Washer - 3/4” Flat 313-2300-023 8 8 8 8
Washer - #8 .019” ID x .044”
OD x .049” Thick
313-2300-123 3 3 3 3
TABLE 1. AutoBoom UltraGlide and UltraGlide XT Kit Contents
Picture Item Description Part Number
2009 Gen I
117-0233-010
Qty.
2009 Gen I
117-0234-010
Qty
2009 Gen II
117-0233-011
Qty.
2009 Gen II
117-0234-011
Qty.
