22 Viper Pro Installation & Operation Manual
ULTRASONIC SENSOR BRACKET KIT.
Hydraulic Hose - -6 ORFS (F) to -6 ORFS
(F) 90° - 24”
214-1001-055 1
Hydraulic Hose - -8 ORFS (F) TO -6 ORFS
(F) 90° - 24”
214-1000-092 1
TABLE 5. Ultrasonic Sensor Bracket Installation Kit - Qty. 2 (P/N 117-0131-082)
Picture Item Description Part Number Qty.
Not Pictured Sheet - AutoBoom Sensor Extension 016-0130-070 1
Nut - 1/4”-20 Nylon Insert Lock 312-4000-057 4
Washer - 1/4” Zinc Flat 313-2300-010 4
Extension Mount - 12” S-Type, Sensor 063-0131-592 2
TABLE 4. UltraGlide XT Hydraulic Installation Kit (P/N 117-0134-094)
Picture Item Description Part Number Qty.
To Next Page
