CHAPTER 3
HYDRAULIC SYSTEM
INSTALLATION
WARNING
The machine must remain stationary and
switched off, with the booms folded and in the
transport position, during installation or
maintenance.
Bleed pressure from the hydraulic system by
operating the boom tilt functions while the key is
on, but the machine’s engine is off.
CAUTION
When installing AutoBoom hydraulics or
performing diagnostics, maintenance, or routine
service, ensure precautions are taken to prevent
any foreign material from being introduced into
the machine’s hydraulic system.
Objects that are able to bypass the machine’s
hydraulic filtration system will reduce
performance and possible damage the
AutoBoom hydraulic valve.
NOTICE
The appearance of the AutoBoom hydraulic valve
may vary slightly from the images contained in
this manual. However, the fittings, hose
connections, and cable connections remain the
same.
