Raven AutoBoom UltraGlide XT User Manual

2
Manual No. 016-0171-122 Rev. E 11
INTRODUCTION
MODEL YEARS 2010 - 2011
TABLE 2. AutoBoom UltraGlide and UltraGlide XT Installation Kits
Picture Item Description Part Number
117-0233-008
Qty.
117-0234-008
Qty.
Not Pictured
Manual - AutoBoom Calibration and
Operation
016-0130-062 1 1
Not Pictured
Manual - RoGator UltraGlide XT
Installation
016-0233-005 1 1
Valve - AutoBoom Add-On Hydraulic 063-0131-131 1 N/A
Valve - AutoBoom XT Hydraulic 063-0131-154 1 1
Node - UltraGlide XT 063-0130-023 1 1
Sensor - Left Ultrasonic 063-0130-014 1 1
Sensor - Ultrasonic Sensor 063-0130-026 4 N/A
Sensor - Rotary Non-Contact Con-X-All
Connector
063-0181-018 1 1
Bracket - Rotary Sensor Mounting 107-0172-177 1 1
