CHAPTER 2
12 Viper Pro Installation & Operation Manual
Bracket - Rotary Sensor Bolt Mounting 107-0172-178 1 1
Bracket - UltraGlide XT Valve Mounting 107-0172-179 1 1
Bracket - UltraGlide XT Rotary Sensor
Mounting
107-0172-268 1 1
Bracket - UltraGlide Node Mounting 107-0172-348 1 N/A
Bracket - UltraGlide XT Sensor Mounting 107-0172-349 1 1
Bracket - Ultrasonic Sensor Weldment
Mounting
116-0159-684 1 1
Cable - 70’ Sensor Extension 115-0171-527 2 2
Cable - 40’ Sensor Extension 115-0171-602 2 2
Cable - RoGator 2010-2011 Aftermarket
Node Harness
115-0230-104 1 1
Cable - RoGator 2010-2011 Aftermarket
CAN/Power
115-0230-105 1 1
TABLE 2. AutoBoom UltraGlide and UltraGlide XT Installation Kits
Picture Item Description Part Number
117-0233-008
Qty.
117-0234-008
Qty.
