INTRODUCTION
Bolt - 5/16”-18 UNC x
4” Machine
311-0052-09222222222
Bolt - 3/8” - 16 UNC 1-
1/4” Machine
311-0054-08144444444
Bolt - 1/2”-13 UNC x
3-1/2” Machine
311-0058-10511111111
Bolt - 3/4”-10 UNC x
4” Machine
311-0062-16044444444
Screw - #8-32 UNC x
1/2” Phillips Panhead
Machine
311-0001-01333333333
Screw - #8-32 UNC x
1-1/4” Phillips Panhead
Machine
311-0001-02333333333
Nut - #8-32 UNC 2B
Hex
312-1001-02066666666
Nut - 3/8”-16 Zinc
Flanged Lock
312-1001-164 30 30 30 30 14 14 14 14
Nut - 5/16”-18 Nylon
Insert Lock
312-4000-05922222222
TABLE 3. AutoBoom UltraGlide and UltraGlide XT Installation Kits
Picture Item Description Part Number
117-0233-005
Qty.
117-0233-016
Qty.
117-0233-017
Qty.
117-0233-018
Qty.
117-0234-005
Qty.
117-0234-016
Qty.
117-0234-017
Qty.
117-0234-018
Qty.
