Raymarine E70533 - 10.9 Radar settings menu

10
.8Sensitivitycontrols
Optimumperformanceisusuallyachievedusingthedefaultsettings.Y ou
maybeabletoenhancetheradarimageusingthesensitivitycontrols.
Sensitivitysettingscanbeaccessedbypressingthe[OK]buttonwhilein
motionmode,orthe[Adjustsensitivity]menu:[Menu>Adjustsensitivity].
.
ControlDescription
[‘G’Gain]
Thecontroldeterminesthesignalstrengthatwhichtarget
returnsareshownonscreen.
Ahighervalueproducesmoretargetreturnsandnoise
onscreen.
[‘R’Rain]
Precipitationappearsontheradarscreenaslotsofsmall
echoeswhichcontinuouslychangesize,intensityand
position.Theraincontrolsuppressestheseechoesmaking
iteasiertoidentifyrealobjects.
Thehighertheraincontrolissetthemoreechoeswillbe
suppressed.
[‘S’Seaclutter]
Radarechoesfromwavescancluttertheradarscreen.
Theseacontrolsuppressestheseechoes(forupto5nm
dependingonconditions)makingiteasiertoidentifyreal
objects.
Thehighertheseacontrolissetthemoreechoeswillbe
suppressed.
ControlDescription
[‘
CG’ColorGain]
Thecontrolsetsthelowerlimitforthecolorusedforthe
strongesttargetreturns.Alltargetreturnsabovethisvalue
aredisplayedinthestrongestcolor.Thosewithaweaker
valuearedividedequallybetweentheremainingcolors.
[AlltoA
uto]
SetsallSensitivitysettingsto[Auto].
10.9Radarsettingsmenu
ThesettingsmenuprovidesaccesstotheRadarapp’ssettingsandoptions.
Transmissiontab
DescriptionOptions
[Scanner]
Displaysthenameoftheconnected
radarscanner
.
N/A
R adarapp
129
