Raymarine E70533 - Boat Details; Units of Measure

Boatdetails
T
oensurecorrectoperationanddisplayofdatayoushouldsettheBoat
Detailssettingsaccordingtoyourrequirements.
Boatdetailscanbeaccessedfromthe[Settings]menu:[Homescreen>
Settings>BoatDetails]
OptionDescription
[Minsafe
height:]
Enteryourvessel’ smaximumunladenheightfrom
thewaterline.T oensureadequateclearance,itis
recommendedthatyouaddasafetymargintothisfigure
toallowforvariationcausedbyvesselmovements.
[Minsafewidth:]Enteryourvessel’ smaximumwidthatitswidestpoint.
Toensureadequateclearanceonbothsides,itis
recommendedthatyouaddasafetymarginforportand
starboardtothisfiguretoallowforvariationcausedby
vesselmovements.
[Minsafe
depth:]
Enteryourvessel’ smaximumdepthwhenfullyladen.
Thisisthedepthfromthewaterlinetothelowestpoint
onthevessel’skeel.Toensureadequateclearance,itis
recommendedthatyouaddasafetymargintothisfigure
toallowforvariationcausedbyvesselmovements.
[Numof
engines:]
Y oucanconfigureyoursystemtodisplaydataforup
to2engines,whenconnectedtoacompatibleengine
managementsystem.
[Identify
engines:]
Onceyouhaveselectedthenumberofengines,select
[Identifyengines]andfollowtheonscreeninstructionsto
configureyourengines.Mayrequireane xtrahardware
interfacetoenableenginedatatobedisplayed.
[Fueltank s:]Y oucanconfigureyoursystemtodisplaydataforup
to2fueltanks.
[Freshwater
tank s:]
Y oucanconfigureyoursystemtodisplaydataforupto
2freshwatertanks.
[Livewelltank s:]Y oucanconfigureyoursystemtodisplaydataforup
to2Livewelltanks.
[Graywater
tank s:]
Y oucanconfigureyoursystemtodisplaydataforaGray
watertank.
OptionDescription
[Blackwater
tank
s:]
Y oucanconfigureyoursystemtodisplaydatafora
Blackwatertank.
[Batteries:]Y
oucanconfigureyoursystemtodisplaydataforupto
3batteries.
[T
ransducer:]
Y oucanselectthetransducertypethatisconnected
toyourdisplay.
Important:
Ensurethedisplayispoweredoffbeforephysically
changingyourtransducer
.
Unitsofmeasure
Youcanselectyourpreferredunitsfordatareadingsfromthe[Units]menu:
[Homescreen>Settings>Units].
Defaultunitsofmeasurearedeterminedbytheselecteduserinterface
language.
MeasurementUnits
[Distanceunits]•[NM&ft]—Nauticalmiles&Feet
•[NM&m]—Nauticalmiles&
Meters
•[mi&ft]—Miles&Feet
•[km&m]—KilometersandMeters
•[NM&yd]—Nauticalmiles&
Y
ards
[Speedunits]•[Kts]—Knots
•[MPH]—Mileperhour
•[KPH]—Kilometersperhour
[Depthunits]•[Meters]—m
•[Feet]—ft
•[Fathoms]—Fm
Homescreen49
