Antennaorientation

adiowavesareemittedfromthewirelesshubperpendiculartotheorientationofthehub’santenna.

K eepingtheantennaverticalshouldprovidethebestcoveragefordevicesonthesameplaneas

yourhub.Positioningtheantennahorizontallywillprovidebettercoverageaboveandbelowthehub.

Installingthewirelesshubantennaextensionaccessory

Anextensioncableaccessory(A80541)isavailableforthewirelesshub’santenna.Usingthe

extensionthedistanceofthewirelesshub’santennacanbeextendedafarther5m(16.4ft).

Antenna(suppliedwith

thehub)

Nut

3M3x10ﬁxingscrewsx3

4Mountingplate

Mountingsurface(14mm

(0 .55in)diameterhole

required)

5m(16.4ft)antennaextensioncable

Splitwasher8

Wirelesshub

1.ChecktheselectedlocationfortheMountingplate ,aclearﬂatareaisrequired.

Installation45
