1.0 BEFORE INSTALLATION
IMPORTANT SAFETY INSTRUCTIONS
• Do not climb or put weight on any door or header parts.
• Do not let children play with the operator, the electrical board, or door control. Keep remote controls away
from children.
• Keep all power off to the unit, when performing any work or maintenance.
• Personnel should keep away from a door in motion and keep the moving door in sight until it is completely
closed or opened. NO ONE SHOULD CROSS THE PATH OF A MOVING DOOR.
• Test the door’s safety features at least once a month. After adjusting either the force or the limit of travel,
retest the door operator’s safety features. Failure to adjust the operator properly may cause severe injury
or death.
• For products having a manual release, if possible, use the manual release only when the door is closed.
Use caution when using this release when the door is open. Weak or broken springs may cause the door
to fall rapidly, causing severe injury or death.
• KEEP DOORS PROPERLY OPERATING AND BALANCED, see AAADM owner’s manual. An
improperly operating or balanced door could cause severe injury or death. Have Record authorized
technician to make repair or maintenance.
To avoid bodily injury, material damage and malfunction of the product, the instructions contained in this manual must
be strictly observed during installation, adjustment, repairs and service etc. Training is needed to carry out
these tasks safely. Only Record-trained technicians should be allowed to carry out these operations.
It is the responsibility of the final installer and/or installation company, to certify that the final
completed operator is installed in accordance with local building codes and applicable laws.
1.3 Technical Specifications
Record HA8-SP
DC16V/ 3 AMP, DC24V/ 3 AMP
1/8 hp, 24VDC/16VDC, 3A (Standard),
Continuous opening and closing cycles
Manual Opening/Closing Force -
during power failure
Opening Force: 15 lbs; Closing Force: 25lbs
Door Opening/Closing Speed & Force
Adjustable, see section 8.0 ADA ADJUSTMENTS
Operation - during power failure
Low manual resistance when opened by hand. Door closing by spring.
Pulsed Energy to Motor. No overheating. Continuous Hold Open
Ambient temperature -4F to +120F (-20C to +50C) No condensation or icing
Ambient humidity 30% to 85% RH
(No hazardous materials must be present in the atmosphere)
Pg. 10
HA8-SP Manual V. 7.0
Record Canada Inc.
Toll Free: 1-877-348-6837
info.ditec.ca@recorddoors.com
www.recorddoors.ca
Record USA Inc.
Toll Free: 1-866-901-4284
info.ditec.us@recorddoors.com
www.recorddoors.com
