6.0 DIGITAL BOARD & PROGRAMMING
6.3 Connection Diagram - Fully Automatic (ANSI A156.10)
A Switch or Jumper must be wired from the ON terminal to the OFF terminal for Programming to work!
Pg. 48
HA8-SP Manual V. 7.0
