6.4 Programming Specification
0 to F
0 = slowest
F = fastest
0 to 5
0 = slowest
5 = fastest
0 to 5
0 = slowest
5 = fastest
0 to 9
0 = slowest
9 = fastest
1 = 2 sec 6 = 12 sec b = 22 sec
2 = 4 sec 7 = 14 sec C = 24 sec
3 = 6 sec 8 = 16 sec d = 26 sec
4 = 8 sec 9 = 18 sec E = 28 sec
5= 10 sec A = 20 sec F = 30 sec
ACTIVATION TIME
The time that the door remains
open, starting when the activation
trigger goes OFF. 2 to 30 sec
0 = 2 sec 4 = 10 sec
1 = 4 sec 5 = 12 sec
2 = 6 sec 6 = 14 sec
3 = 8 sec 7 = 16 sec
DELAY ON OPERATE
The time delay before operating the
door, starting when ACT’N2 trigger
goes ON. 2 to 16sec - This is valid
when Setting A1 has the
LED OFF.
0 = Instant trigger - extremely sensitive
1 = 1/8 sec - very sensitive
2 = 1/4 sec
3 = 3/8 sec - mid range sensitivity
4 = 1/2 sec
5 = 5/8 sec - not sensitive
PUSH AND GO SENSITIVITY
The amount of time that a push and
go trigger must be sensed before
the door is triggered. A longer time
makes the door less sensitive to a
push and go.
1 = 2 sec 6 = 12 sec b = 22 sec
2 = 4 sec 7 = 14 sec C = 24 sec
3 = 6 sec 8 = 16 sec d = 26 sec
4 = 8 sec 9 = 18 sec E = 28 sec
5 = 10sec A = 20 sec F = 30 sec
PUSH AND GO ACTIVATION TIME
The time that the door remains
open starting when the Push and
Go input is triggered.
0 = 0.00 sec
1 = 0.50 sec
2 = 1.00 sec
3 = 1.50 sec
4 = 2.00 sec
SAFETY 1 INHIBIT
The time that a Safety1 input is
ignored (inhibited), starting when
the door goes into Latch.
0 to 2 sec
0 = 0.125 sec
1 = 0.25 sec
2 = 0.50 sec
3 = 1.00 sec
4 = 1.50 sec
5 = 2.00 sec
STRIKE DELAY
The time between Strike ON and
door starting to open.
HA board ONLY
