Record HA8-SP - Page 50

CODE INDICATION
ON/OFF LED = ON
ON/OFF = OFF
DEFAULT
SETTING
FUNCTION
LED
SETTING
LED
A
0
Safety2 OFF at back check
Safety2 always active
LED OFF
A
1
ACT=N1 is connected to a push button
switch and always opens the door.
ACT=N2 is connected to the door and
is only active after ACT’N1 is pressed
and before the door closes and gets to
the Latch point
Activation input 1 (ACT=N1)
works as an instant activation.
Activation input 2 (ACT=N2)
works as a delayed activation
(delay time programmed through
Function A5@.)
LED OFF
ACT=N1 is instant
and
ACT=N2 is
delayed
activation
A
2
Lockout ON – during closing
Safety1 is active if the door stops
moving (from hitting an obstruction for
example). If door is moving then
Safety 1 is NOT active.
Lockout OFF
Safety1 is always active
LED ON
Lockout ON
A
3
Push and Go is active
Push and Go disabled
LED OFF –
Push and Go
Disabled
** Push and Go will only work with an operator WITHOUT a clutch **
A
4
In process of reading out A# of door
opening cycles@
No readout
LED OFF –
no readout
To obtain the number of opening cycles that the door has gone through press the set button while in
the Function A, Setting 4 mode. Example: Readout of 3 2 (pause) 7 0 = 3,270 door cycles
A
5
Safety1 sensor mounted on closing
side of door
Safety1
sensor mounted overhead
LED OFF –
Safety1 mounted
Overhead
A5 –
LED OFF
(Overhead
Sensor)
Door Opening - Safety1 sensor has no effect
Door Fully Open - Safety1 sensor ON = door will not close
Door Closing - A2 setting ON. Door moving = Safety1 has no effect (door will open)
- A2 setting ON. Door stopped, Safety1 ON = door will not open
- A2 setting OFF. Safety1 ON = door will not open
Door fully closed - Safety1 sensor ON = door will not open
A5 –
LED ON
(Door
mounted
Sensor)
Door Opening - Safety1 sensor has no effect
Door Fully Open - Safety1 sensor ON = door will not close
Door Closing - Safety1 sensor ON = door drives at HOLD speed
Door fully closed - Safety1 sensor has no effect
6.0 DIGITAL BOARD & PROGRAMMING
Pg. 50
HA8-SP Manual V. 7.0
