6.1 Digital Board Specification (Single Board)
INPUTS
AC VOLTAGE
ACTIVATION 1
(ACT’N1)
ACTIVATION 2
(ACT’N2)
SAFETY 1
SAFETY 2
- First input to open the door. Instant activation (i.e. push buttons)
- ON = Closed contact to ground/common.
- See Function AA”, Setting A1” for description of alternate operation
- Second input to open the door. Delayed activation.
- ON = Closed contact to ground/common.
- See Function AA”, Setting A1” for description of alternate operation.
- For Safety1 ON door will not open if presently fully closed and door will not close if presently
fully opened (i.e. overhead presence sensors - Bodyguard)
- ON = Closed contact to ground/common.
- For Safety2 ON and Activation1 input ON door will drive at hold speed. If Activation1 input goes
off door closes. If Safety2 goes off door will open. (i.e. Door mounted sensor on swing side -
Superscan)
- ON = Closed contact to ground/common.
OUTPUTS
MOTOR
DATA
_
and DATA+
- 2 motor connectors to drive door in either clockwise or counter clockwise direction.
- Interface with BEA Bodyguard sensor. (replaces LO-21K lockout relay)
OTHER FEATURES
CLOSING SPEED
BACK CHECK and
LATCHING
LOCKOUT
PUSH AND GO
OVERLOAD
ON/OFF/
HOLD OPEN
Adjustable by potentiometer
1 switch for each
Lockout of door while closing is selectable via Function AA”, Setting A2”.
When Push and Go is selected a manual push of the door will trigger the door to open.
Selectable via Function AA”, Setting A3”. Default is OFF
Selectable Overload setting. Adjustable by potentiometer.
Terminal block position to accommodate a 3 way switch for ON, OFF and Hold Open positions.
(Updated Nov 2017)
