Record HA8-SP - Page 67

LOW ENERGY STICKERS
(ON BOTH INGRESS
& EGRESS SIDES)
"IN" DOOR
FULL ENERGY STICKERS
(INGRESS SIDE)
FULL ENERGY STICKERS
(EGRESS SIDE)
"IN" DOOR
WARNING! Before leaving the job site,
• Clean up the work area
• Make sure all bolts are tight
• Clean glass
• Install safety decals
9.0 INSTALLATION WRAP UP
"OUT" DOOR
"OUT" DOOR
50in 1270mm
58in 1473.2mm
50in[
1270mm
]
12in
[
305mm
]
Pg. 67
HA8-SP Manual V. 7.0
