Record HA8-SP - Page 8

Replacement Parts
Item
Category
Part No.
Description
1
Operator
W7-105L
LH 1/8 hp Operator
W7-105R
RH 1/8 hp Operator
W7-106L
LH 1/8 hp Push & Go
Operator
W7-106R
RH 1/8 hp Push & Go
Operator
2
Header Cap
W5-557
Header Plastic Cap
3
Control Board
W7-130-1
HA Digital Control Board
W7-135-1
FA Digital Control Board
W7-180
Dual Digital Control Board
(FA8 only)
4
HA8 Fuse
W5-422
3AMP Fuse
FA8 Fuse
W5-430
4AMP Fuse
5
Push Arm
W7-200
Complete Push Arm-Clear
(with 17.5” rod)
W7-205
Complete Push Arm-Bronze
(with 17.5” rod)
W5-502C
Cast portion only - Clear
W5-502B
Cast portion only - Bronze
W5-500C
Extended Rod (22”) - Clear
W5-500B
Extended Rod (22”) - Bronze
6
Z-Arm (Pull)
W5-506C
Z-Arm RH - Clear
W5-505C
Z-Arm LH - Clear
W5-506B
Z-Arm RH - Bronze
W5-505B
Z-Arm LH - Bronze
W5-508C
Extended Z-Arm RH - Clear
W5-508B
Extended Z-Arm RH - Black
W5-507C
Extended Z-Arm LH - Clear
W5-507B
Extended Z-Arm LH - Black
Replacement Parts
Item
Category
Part No.
Description
7a
Pull Arm Track
- Short
(for Z-arm)
W5-550
Pull Track Assembly-Clear
W5-555
Pull Track Assembly-Bronze
7b
Pull Arm Track
- Long
(for Universal Arm/
Center Spindle)
W5-551
Pull Track Assembly Long
- Clear
W5-556
Pull Track Assembly Long
- Bronze
8
Universal Arm
W5-512C
Universal Arm - Clear
W5-512B
Universal Arm - Bronze
9
Center Hung
Arm
W5-520
Center Hung Arm 2 ¾”
W5-521
Center Hung Arm 3 ¾”
10
Center Spindle
Arm
W5-511C
Center Spindle LH - Clear
W5-510C
Center Spindle RH - Clear
W5-511B
Center Spindle LH - Bronze
W5-510B
Center Spindle RH - Bronze
11
AUX Power
Supply Kit
(Optional)
WL-
PWRKIT
RS-25-24
Power Supply Kit
12
Rocker Switch
WL-
ROCKER
SWITCH
ON/OFF/HOLD OPEN
3 position switch
13
Magnets Sets
W5-416
Detects Back check and
Latch check phases
14
Reed Switch
W5-415
Communicates to Control
Board the position of door
15
Harness Cable
W5-415-2
Communicates to Control
Board the position of door
