22
• Adjust the survey size and location to your
needs.
• Select DONE WITH POLYGON when finished.
• Select the camera that you would like to use
from the drop-down menu.
• Adjust the percentage of overlap or ground
resolution, if needed.
Make sure to verify the altitude when
adjusting the ground resolution
settings.
• Go to the GRID window to adjust the angle of
the survey to minimize turns, altitudes, and
entry points to adjust the length of the flight.
Select WAYPOINT.
• Add one additional
waypoint toward the exit point of the
survey pattern.
• Set the gimbal to 0°.
Select RETURN.
• This will create the RTL
point. This can be any location but is
usually the same as the take-off point.
Select either UPLOAD REQUIRED to load
the mission onto the drone or select FILE to save the
mission and upload at a later time.
PROGRAMMING A GEOFENCE
Use this option to setup a Geofence within a mission.
Note that a Geofence can also be programmed
separately from a mission in the SAFETY SETTINGS page
by following the instructions in the following
VEHICLE
SETUP section.
Select FENCE in the MISSION PLAN window.
Select the desired geofence perimeter shape and then
select the area on the map, or select the free-form
option and create the desired perimeter on the map.
Select DONE.
Select either UPLOAD REQUIRED to load the mission
onto the drone or select FILE to save the mission and
upload at a later time.
NOTE: Only one mission can be on the
drone at a time. If you upload a new
mission, it will overwrite the current
mission.
PROGRAMMING A RALLY POINT
Touch the MENU icon.
Select PLAN.
A MISSION PLAN window will appear.
Select RALLY.
• Add the rally point by touching the location on
the map or by entering the exact coordinates
in the field provided.
Select either UPLOAD REQUIRED to load the mission
onto the drone or select FILE to save the mission and
upload at a later time.
NOTE: The drone will go to the RTL or
rally point, whichever is closest to the
drone.
