Renesas R8C series

B - 1
NOTE:
1. The blank regions are reserved.
Do not access locations in these regions.
Address Register Symbol Page
0000h
0001h
0002h
0003h
0004h Processor Mode Register 0 PM0 55
0005h Processor Mode Register 1 PM1 56
0006h System Clock Control Register 0 CM0 60
0007h System Clock Control Register 1 CM1 61
0008h
0009h Address Match Interrupt Enable Register AIER 99
000Ah Protect Register PRCR 77
000Bh
000Ch Oscillation Stop Detection Register OCD 62
000Dh Watchdog Timer Reset Register WDTR 105
000Eh Watchdog Timer Start Register WDTS 105
000Fh Watchdog Timer Control Register WDC 104
0010h Address Match Interrupt Register 0 RMAD0 99
0011h
0012h
0013h
0014h Address Match Interrupt Register 1 RMAD1 99
0015h
0016h
0017h
0018h
0019h
001Ah
001Bh
001Ch Count Source Protection Mode Register CSPR 105
001Dh
001Eh
INT0 Input Filter Select Register
INT0F 91
001Fh
0020h High-Speed On-Chip Oscillator Control
Register 0
HRA0 63
0021h High-Speed On-Chip Oscillator Control
Register 1
HRA1 64
0022h High-Speed On-Chip Oscillator Control
Register 2
HRA2 64
0023h
0024h
0025h
0026h
0027h
0028h
0029h
002Ah
002Bh
002Ch
002Dh
002Eh
002Fh
0030h
0031h Voltage Detection Register 1 VCA1 47
0032h Voltage Detection Register 2 VCA2 47
0033h
0034h
0035h
0036h Voltage Monitor 1 Circuit Control Register VW1C 48
0037h Voltage Monitor 2 Circuit Control Register VW2C 49
0038h
0039h
003Ah
003Bh
003Ch
003Dh
003Eh
003Fh
Address Register Symbol Page
0040h
0041h
0042h
0043h
0044h
0045h
0046h
0047h
0048h
0049h
004Ah
004Bh
004Ch
004Dh Key Input Interrupt Control Register KUPIC 83
004Eh A/D Conversion Interrupt Control Register ADIC 83
004Fh SSU/IIC Interrupt Control Register SSUAIC/IIC2AIC 83
0050h Compare 1 Interrupt Control Register CMP1IC 83
0051h UART0 Transmit Interrupt Control Register S0TIC 83
0052h UART0 Receive Interrupt Control Register S0RIC 83
0053h UART1 Transmit Interrupt Control Register S1TIC 83
0054h UART1 Receive Interrupt Control Register S1RIC 83
0055h
0056h Timer X Interrupt Control Register TXIC 83
0057h
0058h Timer Z Interrupt Control Register TZIC 83
0059h INT1 Interrupt Control Register INT1IC 83
005Ah INT3 Interrupt Control Register INT3IC 83
005Bh Timer C Interrupt Control Register TCIC 83
005Ch Compare 0 Interrupt Control Register CMP0IC 83
005Dh INT0 Interrupt Control Register INT0IC 84
005Eh
005Fh
0060h
0061h
0062h
0063h
0064h
0065h
0066h
0067h
0068h
0069h
006Ah
006Bh
006Ch
006Dh
006Eh
006Fh
0070h
0071h
0072h
0073h
0074h
0075h
0076h
0077h
0078h
0079h
007Ah
007Bh
007Ch
007Dh
007Eh
007Fh
SFR Page Reference
