B - 2
NOTE:
1. The blank regions, 0100h to 01B2h, and 01C0h to 02FFh
are reserved.
Do not access locations in these regions.
Address Register Symbol Page
0080h Timer Z Mode Register TZMR 124
0081h
0082h
0083h
0084h Timer Z Waveform Output Control Register PUM 126
0085h Prescaler Z Register PREZ 125
0086h Timer Z Secondary Register TZSC 125
0087h Timer Z Primary Register TZPR 125
0088h
0089h
008Ah Timer Z Output Control Register TZOC 126
008Bh Timer X Mode Register TXMR 110
008Ch Prescaler X Register PREX 111
008Dh Timer X Register TX 111
008Eh Timer Count Source Setting Register TCSS 111,127
008Fh
0090h Timer C Register TC 143
0091h
0092h
0093h
0094h
0095h
0096h External Input Enable Register INTEN 91
0097h
0098h Key Input Enable Register KIEN 97
0099h
009Ah Timer C Control Register 0 TCC0 144
009Bh Timer C Control Register 1 TCC1 145
009Ch Capture, Compare 0 Register TM0 143
009Dh
009Eh Compare 1 Register TM1 143
009Fh
00A0h UART0 Transmit/Receive Mode Register U0MR 155
00A1h UART0 Bit Rate Register U0BRG 154
00A2h UART0 Transmit Buffer Register U0TB 154
00A3h
00A4h UART0 Transmit/Receive Control Register 0 U0C0 156
00A5h UART0 Transmit/Receive Control Register 1 U0C1 157
00A6h UART0 Receive Buffer Register U0RB 154
00A7h
00A8h UART1 Transmit/Receive Mode Register U1MR 155
00A9h UART1 Bit Rate Register U1BRG 154
00AAh UART1 Transmit Buffer Register U1TB 154
00ABh
00ACh UART1 Transmit/Receive Control Register 0 U1C0 156
00ADh UART1 Transmit/Receive Control Register 1 U1C1 157
00AEh UART1 Receive Buffer Register U1RB 154
00AFh
00B0h UART Transmit/Receive Control Register 2 UCON 157
00B1h
00B2h
00B3h
00B4h
00B5h
00B6h
00B7h
00B8h SS Control Register H / IIC bus Control
Register 1
SSCRH / ICCR1 172, 202
00B9h SS Control Register L / IIC bus Control
Register 2
SSCRL / ICCR2 173, 203
00BAh SS Mode Register / IIC bus Mode Register SSMR / ICMR 174, 204
00BBh SS Enable Register / IIC bus Interrupt
Enable Register
SSER / ICIER 175, 205
00BCh SS Status Register / IIC bus Status Register SSSR / ICSR 176, 206
00BDh SS Mode Register 2 / Slave Address
Register
SSMR2 / SAR 177, 207
00BEh SS Transmit Data Register / IIC bus
Transmit Data Register
SSTDR / ICDRT 178, 207
00BFh SS Receive Data Register / IIC bus Receive
Data Register
SSRDR / ICDRR 178, 208
Address Register Symbol Page
00C0h A/D Register AD 235
00C1h
00C2h
00C3h
00C4h
00C5h
00C6h
00C7h
00C8h
00C9h
00CAh
00CBh
00CCh
00CDh
00CEh
00CFh
00D0h
00D1h
00D2h
00D3h
00D4h A/D Control Register 2 ADCON2 235
00D5h
00D6h A/D Control Register 0 ADCON0 234
00D7h A/D Control Register 1 ADCON1 234
00D8h
00D9h
00DAh
00DBh
00DCh
00DDh
00DEh
00DFh
00E0h
00E1h Port P1 Register P1 29
00E2h
00E3h Port P1 Direction Register PD1 29
00E4h
00E5h Port P3 Register P3 29
00E6h
00E7h Port P3 Direction Register PD3 29
00E8h Port P4 Register P4 30
00E9h
00EAh Port P4 Direction Register PD4 29
00EBh
00ECh
00EDh
00EEh
00EFh
00F0h
00F1h
00F2h
00F3h
00F4h
00F5h
00F6h
00F7h
00F8h Port Mode Register PMR 30, 178, 208
00F9h
00FAh
00FBh
00FCh Pull-Up Control Register 0 PUR0 31
00FDh Pull-Up Control Register 1 PUR1 31
00FEh Port P1 Drive Capacity Control Register DRR 31
00FFh Timer C Output Control Register TCOUT 146
01B3h Flash Memory Control Register 4 FMR4 257
01B4h
01B5h Flash Memory Control Register 1 FMR1 256
01B6h
01B7h Flash Memory Control Register 0 FMR0 255
0FFFFh Optional Function Select Register OFS 104, 250
