REVISION HISTORY R8C/1A Group, R8C/1B Group Hardware Manual
1.10 Mar 17, 2006 − Products of PWQN0028KA-B package included
1“or SDIP”
→ “SDIP or a 28-pin plastic molded-HWQFN”
2, 3 Table 1.1, Table 1.2; “28-pin molded-plastic HWQFN” added
5, 6 Table 1.3, Table 1.4; Type No. added, deleted
9 Figure 1.6 added
12 Table 1.7 added
16, 17 Figure 3.1, Figure 3.2; Part Number added, deleted
40 6.2 “When a capacitor is connected to ... pin 0.8VCC or more.” added
57 Figure 10.1 revised
66 Table 10.2; CM1 Register; CM17, CM16 revised
101 Figure 13.2; Option Function Select Register:
NOTE 1 revised, NOTE 2 revised
Watchdog Timer Control Register: NOTE 1 deleted
110 Table 14.3; NOTE 1 added
139 Figure 14.25 revised
146 Table 14.12; NOTE 1 revised
151 Figure 15.3; NOTE 3 added
153 Figure 15.5; NOTE 1 added
166 Table 16.1 revised
167 Table 16.2; NOTE 1 deleted
175 Figure 16.8 SS Transmit Data Register; The last NOTE 1 deleted
182, 186,
190
16.2.5.2, 16.2.5.4, 16.2.6.2
“When setting the microcomputer to....continuous transmit is enabled.”
deleted
183, 187 Figure 16.14 NOTE 2 deleted
235 Table 17.3 revised
240 17.7 added
248 18.3.2; “To disable ROM code protect ....” revised
Figure 18.4; NOTE 1 revised, NOTE 2 added
253 Figure 18.5; NOTE 6 added
263 Table 18.5; Value after Reset revised
265 Figure 18.15 revised
275 Table 19.4;
“Topr”
→ “ Ambient temperature ”,
Conditions: V
CC = 5.0 V at Topr = 25 °C deleted, NOTE 8 added
276 Table 19.5;
“Topr”
→ “ Ambient temperature ”,
Conditions: V
CC = 5.0 V at Topr = 25 °C deleted, NOTE 9 added
279 Table 19.10; NOTE 3 added
280 Table 19.12; Standard of tSA and tOR revised, NOTE: 1. VCC = 2.2 to →
2.7 to
