REVISION HISTORY R8C/1A Group, R8C/1B Group Hardware Manual
1.10 Mar 17, 2006 284 Table 19.13; NOTE: 1. VCC = 2.2 to → 2.7 to
286, 290 Table 19.15, Table 19.22; The title revised, Condition of Stop Mode “Topr
= 25
°
C” added
288, 292 Table 19.19, Table 19.26; Standard of td(C-Q) and tsu(D-C) revised
307,308 Package Dimensions revised, added
309 Appendix Figure 2.1 revised
310 Appendix Figure 3.1 revised
1.20 Oct 03, 2006 all pages Y version added
Factory programming product added
2, 3 Table 1.1, Table 1.2; Specification Interrupts: “Internal: 9 sources” →
“Internal: 11 sources”
34 Table 5.12 Setting Value revised
39 Table 6.2 “Pin Functions after Reset” → “Pin Functions while RESET Pin
Level is “L””
64 Figure 10.6; HRA1 NOTE 2 added, HRA2 NOTE 5 added
75 10.6.1 revised, 10.6.2 added
103 Figure 13.2; WDC: After Reset “When read, the content is undefined.”
added
120 Figure 14.10 pulled up added, NOTE 6 “In this case, .... of the read-out
buffer.” deleted, NOTE 7 deleted
164 Figure 15.10 revised
172 Figure 16.3; SSCRL NOTE 2 revised
203 Figure 16.26 NOTE 3 revised
210 to 215
Figure 16.32 to Figure 16.36 revised
250 Table 18.3 Item; Modes after read status register added
257 Figure 18.8 revised
260 18.4.3.1 “In addition, .... after a reset.” added
18.4.3.2 “The MCU remains in read .... command is written.” added
261 18.4.3.4 “The FMR00 bit is set to 0 during .... 1 when auto-programming
completes.” → “When suspend function .... 0 when autoprogramming
completes.” revised
262 Figure 18.13 added
264 Figure 18.15 revised
267 Figure 18.16 revised
275 Table 19.2; Parameter: System clock added
308 21. (2) revised, (5) deleted
310 Package Dimensions; PWQN0028KA-B revised
1.30 Dec 08, 2006 20 Table 4.1; 000Fh: After reset “000XXXXXb” → “00X11111b”
36 Table 5.17 Setting Value revised
60 Figure 10.2 NOTE 4 revised
