b) Preassembled Device
(1) Display
(2) Extrudercarriage
(3) MotorfortheX-direction
(4) Operatingswitch
(5) Filamentfeed
(6) Aluminiumprintingplateandheater
(7) MotorfortheZ-direction
(8) Filamentholder
Inthesmallgureontheright,theprintingdirections(x,yandz)areindicatedin
the front view.
 Thethreeyellowarrowsinthegureaboveshowtheactualdirectionsinthedis-
played printer.
The preassembled device has an aluminium printing plate with heating in contrast to the maker kit. The preassembled device also
hasametalhousing.Theheatingandhousingcanberetrottedwiththeconstructionkit.
1
5
3
2
6
7
8
4
Z
Y
X
Z
X
Y
